Monitoring software

To monitor the UPS status and schedule shutdown and start ups, connect the UPS to a PC running the monitoring software. Follow these steps to install the software:

1. Use the supplied RS-232 or USB cable to connect the UPS to the PC. If using an SNMP card (sold separately), power off the UPS before installing it.

   USB port



   RS-232



   SNMP Intelligent slot



2. Download the software from this link (link incoming).

3. Follow the on-screen instructions to install the software. Installation requires the PC to restart.

4. After your computer restarts, the monitoring software appears as an orange plug icon in the system tray, near the clock.
