ACC port connection

To unlock the adapter features in OvrC, you must connect it to a compatible 800 or 820-series WattBox PDU on firmware version 2.6.0.8 or newer.

Use TIA-568B Cat5e/6 complying with the NEC type cables category DUZX no longer than 15m (50') to connect the Accessory Adapter to an 800 series PDU. This connection provides power to the adapter.

It takes about two to three minutes for OvrC to recognize the Accessory Adapter.

Note: The WB-800CH1U-IPVM-8 and WB-820CH1U-IPVM-8 are not compatible.
